| DESIGN |
2-driver, 2-way in-ceiling, 30°-Angled Guided Soundfield System SHOCK-MOUNT™ System, Nylon Reinforced Baffle |
| CROSSOVER |
2nd-order electro- acoustic at 2.0 kHz |
| HIGH FREQUENCY DRIVER |
1” (2.5cm) Aluminum Magnesium Ceramic (AL-MAC™) Tweeter with Exclusive Perforated Phase-Aligning (PPA™) Tweeter Lens and Reduced Edge Diffraction (RED™) Technology |
| FREQUENCY RESPONSE ON-AXIS
|
±3 dB from 58 Hz - 22 kHz |
| FREQUENCY RESPONSE 30° OFF-AXIS
|
±3 dB from 58 Hz - 18 kHz |
| MID/BASS FREQUENCY DRIVER |
8” (20.3cm) CARBON-X™ Cone with overmolded Active Ridge Technology (ART™) surround, Advanced Shock-Mount™ System, FEA-Optimized Ultra Rigid Cast- Aluminium Baskets |
| SENSITIVITY ROOM / ANECHOIC |
93 dB / 89 dB |
| LOW FREQUENCY EXTENSION |
39 Hz |
| SUITABLE AMPLIFIER POWER RANGE |
15-110 W |
| MAXIMUM INPUT POWER |
80 W |
| IMPEDANCE |
Compatible with 8 ohms |
| CUT-OUT DIMENSIONS |
11-7/16” (29.1cm) dia. |
MINIMUM MOUNTING DEPTH
(DEPTH REQUIRED IS THE DISTANCE BETWEEN 1/2" DRYWALL, OR SIMILAR MATERIAL.)
|
5-5/8” (14.3cm) |
| DIMENSIONS HXWXD (INCLUDES GRILLE).
|
12-5/8” (diameter) x 6-1/8” (depth) (32.0cm x 15.5cm) |
| WEIGHT |
6.6 lbs (3 kg) |
| FINISHES |
White, paintable grille, black speaker |
