Tonewinner 11 ch home theater theatre audio best pure power amplifier
AD-8300PA is an 11 channels high power audio home theater amplifier with special output power design, which offers 320W/8Ω for left, right & center channels, and 150W/8Ω for the other eight channels. It takes the advantages of different circuits to achieve low distortion and low power consumption, and works better in home theater with high sound pressure & dynamic range.As a top 10 audio brand in China, Tonewinner has 30+ years experience in designing and manufacturing acoustic products. As an original supplier, Tonewinner always warmly welcomes distributors, partners and customers around the world.
AUDIO SPECIFICATIONS (HIGH-POWERED SINGLE CHANNEL MODULES): LCR CHANNELS & SURROUND CHANNELS
- LCR Channels 350 Watts & LS,RS,LBS,RBS 155 Watts RMS/channel; 20 Hz – 20 kHz; THD<0.1%; 8 Ohms; one channel driven
- LCR Channels 605 Watts & LS,RS,LBS,RBS 276 Watts RMS/channel; 20 Hz – 20 kHz; THD<0.2%; 4 Ohms; one channel driven
- LCR Channels 320 Watts & LS,RS,LBS,RBS 150 Watts RMS/channel; 20 Hz – 20 kHz; THD<0.1%; 8 Ohms; Two channel driven
- LCR Channels 516 Watts & Surround Modules 207+ Watts RMS/channel; 20 Hz – 20 kHz; THD<0.1%; 4 Ohms; Two channel driven
- LCR Channels 240+ Watts & Surround Modules 105+ Watts RMS/channel; 20 Hz – 20 kHz; THD<0.1%; 8 Ohms; all channel driven
| Parameters | AD-8300PA | Rated impedance | 8 ohms |
| SNR | ≥110dB(A weight) | Unit gain | 29dB |
| THD | ≤0.03%(1KHZ, normal working condition) | Unit size | 450mmX460mmX210mm |
| Power output/channel | 300W*3+155W*8 (8Ω,THD=1%,1KHz) | N.W | 20KG |
| Frequency range | 10Hz-118KHz(+1/-3dB) | Material | Aluminum alloy |
| Channel | 11 | Accessories | Manual, guarantee card, power cord and signal wire |
| Applicable places | Living rooms, custom installation, experience rooms, clubs, K auditions and other high-end audio-visual rooms. | Colour | Black |
