McIntosh MB20 Bluetooth 5.0 receiver and transmitter

Description

Please note due to McIntosh's global policy this can not be "added to cart" Please call us on 07 3552 7000 to discuss pricing and availability.

As a transmitter/receiver, the MB20 has been designed to provide a superior Bluetooth connection to audio equipment that lacks Bluetooth connectivity. As such, it has been engineered as a Class 1 Bluetooth device. Class 1 devices can typically operate at a range of up to 150 feet (45.7 meters)¹ in ideal conditions with limited obstructions. As a Receiver, the MB20 employs an extremely sensitive receiver for better reception, even from Class 2 devices, with the maximum range determined by the capabilities of both actively paired devices. An external antenna helps maximize its range for better performance. As a Transmitter, it has a range 10x greater than that of a typical Class 2 Bluetooth device.

Supports AAC and aptX HD; 32-bit / 192kHz DAC.

Use 2 units as a wireless bridge between 2 systems.

Balanced & unbalanced in/out; optical & coax in/out



Specifications

• Total Harmonic Distortion

  < 0.005%

• Frequency Response

  +/-0.5dB from 20Hz to 20,000Hz

• Maximum Volts Out (Balanced / Unbalanced)

  5/2.5 V RMS

• Signal To Noise Ratio

  > 100dB

• Output Impedance

  Minimum load 500 Ohms

• Dynamic Range

  N/A

CONNECTIVITY

• Balanced Input

  1

• Balanced Output

  1

• Unbalanced Input

  1

• Unbalanced Output

  1

• Digital Coaxial Input

  1

• Digital Coaxial Output

  1

• Digital Optical Input

  1

• Digital Optical Output

  1

• Digital USB Input

  0

• Digital USB Audio Output

  0

• Network Connection

  Bluetooth

• DVI Output

  0

• HDMI Output

  0

• VGA Output

  0

• eSata Input

  0

DIGITAL AUDIO SPECIFICATIONS

• Digital Input Format

  PCM

• Digital Input Sample Rate

  Up to 24-Bit/192kHz

• Digital Output Format

  24-Bit/96kHz

• Digital Output Sample Rate

  96kHz

CONTROL

• Power Control Input

  0

• Power Control Output

  0

• Rear Panel Data Input

  0

• Rear Panel IR Sensor Input

  0

WEIGHTS & DIMENSIONS

• Unit Dimensions (W x H x D)

  9-29/64″ (24cm) x 2-1/2″ (6.35cm) (antenna in upright position adds additional 1-3/8″ (3.43cm) x 3-15/16″ (10.01cm)

• Unit Weight

  2.5 lbs (1.2kg)

• Shipping Weight

  3.5 lbs (1.6kg)
