Description
The Features
- High-performance chassis with six-way, hand-wound voice coils.
- Digital diaphragm control with 16,000 samples per second
- High-precision automatic calibration with software connection for fine tuning
- Powerful amplifiers with 1,250 watts RMS and 3,000 watts impulse power
| Driver | 18″ forward firing | |||
|---|---|---|---|---|
| Amplifier Class D | 3000 watts dynamic 1250 watts RMS power |
|||
| Frequency Response: Overall Frequency Response: (± 3 dB) |
8.8 – 300 Hz 14.4 – 120 Hz |
|||
| THD | < 0.5 % (typical) | |||
| High Pass Crossover | 80 or 100 Hz at 6 dB/octave | |||
| Low Pass Crossover | 40 Hz to 199 Hz (variable in 1 Hz increments) selectable slope Default: 80 Hz @ 24 dB/Octave |
|||
| Phase | 0 to 180 degrees (variable in 15 degree increments) | |||
| Polarity | Adjustable (+/-) | |||
| Magnet Structure | 39.7 lbs. | |||
| Voice Coil | Six-layer, 75 mm | |||
| Cone | Fiberglass Rohacell Laminate | |||
| Input LFE (Mono) | Line level (RCA), Nominal Impedance 47K, Balanced (XLR), Nominal Impedance 10K | |||
| Input L&R | Line level (RCA & XLR) | |||
| Input Microphone | Balanced (Mini-XLR, cable included) | |||
| Input Speaker Level (L&R) | Bare wire, banana plugs, or spade lugs | |||
| Output Thru (L&R) | Line level (RCA & XLR) | |||
| Output (L&R), High-Pass (L&R) | Line level (RCA & XLR) | |||
| Included Accessories | Full feature remote control, DD+ accessory kit and video cable | |||
| Finishes | Black gloss ebony or Piano Black | |||
| Dimensions (H/W/D) (includes feet and connectors) | 22.7” x 20.7” x 25.6” (58 x 53 x 65 cm) | |||
