Package Includes
Krix Equinox MK4 x 2 Pair's (Front & Rears)
Krix Graphix (Centre)
Krix Seismix 1 MK6
Krix is an Australian owned and operated company based in Adelaide, with more than 45 years experience they mean business when it comes to theatre - that's why they do over 80% of Australian commercial cinemas!
Small bookshelf speakers with big sound? No problem! Just have a listen, reinforced by the Seismix 1 you are sure to be impressed!
Krix Equinox
Frequency Range
45Hz-40kHz in room response
Power Handling
20 – 120 Watts RMS recommended amplifier power
Sensitivity
88dB for 2.83 volts at 1 metre
Impedance
Nominally 6 Ohms (minimum 3.6 Ohms)
Configuration
2-way
Enclosure Type
Bass reflex, rear vented
Dimensions
295mm high x 175mm wide x 235mm deep
Low Frequency Driver
Cast aluminium basket with a nominal 130mm (5″) doped curvilinear paper cone. 30mm (1.2″) vented magnet voice coil wound on high temperature kapton former, with copper shorting ring
High Frequency Driver
26mm (1″) dual concentric diaphragm with wave-guide centre plug for controlled directivity. Non-reflective dual chambered magnet structure with copper shorting ring to lower distortion
Input Terminals
Gold plated binding posts
Weight
6kg each
Krix Graphix
Frequency Range
45Hz-40kHz in room response
Power Handling
20 – 160 Watts RMS recommended amplifier power
Sensitivity
89dB for 2.83 volts at 1 metre
Impedance
Nominally 6 Ohms (minimum 4.3 Ohms)
Configuration
D-Appolito, 2-way
Enclosure Type
Bass reflex, front vented
Dimensions
180mm high x 450mm wide x 300mm deep
Low Frequency Drivers
Fibre reinforced moulded polymer baskets with 2 x nominal 130mm (5″) doped paper cones. 25mm (1″) voice coil wound on high powered aluminium former, with vented magnet assembly
High Frequency Driver
26mm (1″) dual concentric diaphragm with wave guide centre plug for controlled directivity. Neodymium magnet
Input Terminals
Gold plated binding posts
Weight
10kg each
Krix Seismix 1
Frequency Range
25Hz-200Hz in room response
Amplifier Power
350 Watts RMS, 700 Watts maximum instantaneous power
Output
116dB maximum SPL in room response
Inputs
Stereo line level RCA
Enclosure Type
Bass reflex, down firing vent
Dimensions
375mm high x 295mm wide x 320mm deep
Low Frequency Driver
Nominal 200mm (8”) diameter doped paper cone driver, 38mm (1.5″) voice coil wound on high powered aluminium former, with vented magnet assembly
Power On/Off
Signal sensing, 15 minute delay before switching to standby after no input signal
Phase Select
0º to 180º continuously variable (relative to input signal)
Low Pass Filter
50Hz-200Hz or bypass
Weight
11kg each
If you are after a different colour then please reach out to us on either of the below:
07-3552-7000
sales@livingsound.com.au
